Sample Type
Whole blood, Serum, Plasma, Dialysate, CSF
Model name & test items
BG-800 (pH/pCO2/pO2/K+/Na+/CI-/Ca++/Hct )
BG-800A (pH/ pCO2/ pO2 /Hct )
BG-800B (pH/pCO2/pO2/K+/Na+/CI-/Hct )
BG-800E (pH/pCO2/pO2/K+/Na+/CI-/Ca++/Hct /Glu/Lac)
Working environment
Working temperature：15℃~30℃
Storage environment：5℃~45℃
Power supply：100-240V~±10&，50/60±1Hz Power：150VA
Dimension (Length*width*Height) 420mm×623mm×410mm
Weight 25KG
Main Characteristics
--Multi-combination parameters
--Self-made maintenance free electrodes
--Both for syringes & capillary
--35UL for capillary, 95UL for whole blood
--1 min from the aspiration to result
--Long-lasting fluid system
--All-in-one design calibrate cartridge
--Cartridge expiration alarm & residue
--Preheats reagents & sample
--Optional Auto QC cartridge with H/M/L level
--Data storage >5,000
--Colorful touch screen with high resolution
--Friendly operation interface
--Infrared human-detector
--Rich data management interface
--Battery backup
--Build-in thermal printer
--Convenient bar-code system management
--Economic cost per test
Measured Parameters
|
Analyte |
Measuring range |
Unit |
|
pH(CH) |
6.000-9.000 |
|
|
pCO2 |
1.607-26.67 |
kpa |
|
8.0-200.0 |
mmHg |
|
|
pO2 |
0-106.7 |
kpa |
|
0-800.0 |
mmHg |
|
|
K |
0.5-15.0 |
mmol/L |
|
Na+ |
20.0-200.0 |
mmol/L |
|
CI- |
20.0-200.0 |
mmol/L |
|
Ca++ |
0.3-5.0 |
mmol/L |
|
HCT |
12.0-65.0 |
% |
|
B.P. |
500-800 |
mmHg |
|
Glucose |
1.1-66.7 |
Mmol/L |
|
Lactate |
0.4-30.0 |
Mmol/L |
