Specification
|
Model |
Q1000 |
|
Block Sample Capacity |
48-well * 0.1ml |
|
Reaction Volume |
10-50ul |
|
Tubes Option |
Low-profile white or clear 0.1ml PCR tube/eight strip tubes with optical flat cap |
|
Heating and Cooling Technology |
The newest generation of Peltier technology for more than one million thermal cycles |
|
Control Methods |
Operate via PC remote contro; or the touch screen on instrument with limited function |
|
Language |
English |
|
Communications |
USB 2.0 and LAN, export data via USB flash drive |
|
Display |
7'' Color TFT Touch Screen |
|
Temperature |
|
|
Block Temperature Range |
0℃～105℃ |
|
Max. Heating Rate |
7℃/s |
|
Max. Cooling Rate |
6℃/s |
|
Temperature Uniformity |
≤±0.2℃ (at 90℃) |
|
Temperature Accuracy |
≤±0.2℃ (at 90℃) |
|
Display Resolution |
0.1℃ |
|
Ramping Rate Adjustable |
Yes |
|
Mode of Temperature Control |
Sim-tube & Block |
|
Optical Module |
|
|
Excitation |
Long life LED |
|
Detection |
High sensitivity photoelectric detector |
|
Calibrated Dyes at Installation |
Channel 1：FAM、SYBR, Channel 2：VIC、HEX、JOE |
|
Fluorescence Excitation Range |
470 — 500nm |
|
Fluorescence Detection Range |
Channel 1：520 — 540nm, Channel 2：540 — 700nm |
|
Data Export Formats |
Excel, TXT |
|
Computer |
|
|
Operating Systems |
Windows7、Windows8、Windows10 |
|
CPU Speed |
2.0 GHz |
|
Display Resolution |
1366×768 |
|
Memory |
2.00 GB RAM |
|
Available Hard Disk |
＞ 20 GB |
|
Other Features |
|
|
Power |
Global switch power supply: 85V-265V, 50-60Hz |
|
Consumption |
400W |
|
Net Weight |
8.2KG |
|
Dimensions (w x d x h) |
205×250×320mm |
