Specification
|
Model |
T20 |
|
Sample Block |
2*48wells*0.2ml |
|
Tube Optional |
0.2ml PCR tubes, 8 stripes |
|
Peltier Technology |
New generation peltier technology, allow 1,000,000 cycles |
|
Display |
10” Full Color Touch Screen with adjustable angle, graphically |
|
Language |
English |
|
Communications |
2 USB and LAN |
|
Temperature |
|
|
Block Temperature Range |
0℃～105℃ |
|
Max. Heating Rate |
7.5℃/s |
|
Max. Cooling Rate |
6℃/s |
|
Temperature Uniformity |
≤±0.2℃ (at 90℃) |
|
Temperature Accuracy |
≤±0.2℃ (at 90℃) |
|
Display Resolution |
0.1℃ |
|
Ramping Rate Adjustable |
Yes |
|
Mode of Temperature Control |
Sim-tube & Block |
|
Gradient |
|
|
Gradient Accuracy |
≤±0.1℃ (at 90℃) |
|
Column Uniformity |
≤±0.2℃ (at 90℃) |
|
Gradient Range |
30℃～105℃ |
|
Temp. Differential Range |
1～25℃ |
|
Gradient Capability |
Each individual block has 8 gradient temperatures |
|
Heat Lid |
|
|
Lid Temperature Range |
30℃～112℃ |
|
Open Method |
Innovative TOP-OPEN technology, with excess even pressure of heat lid |
|
Auto Shut-Off |
Yes,lid will shut off automatically when the block temperature below set temperature |
|
Software |
|
|
Max. number of programs |
Max. 15,000 programs onboard, unlimited storage of protocols with USB flash drive |
|
Max. Step |
30 Steps, multiple nesting cycle available |
|
Max. Cycle |
100 Typical Cycles (multiple nesting allows 10,000 cycles) |
|
Time Increment/Decrement |
1-120 sec, available for Long PCR |
|
Temperature Increment/Decrement |
0.1-10.0℃, available for Touchdown PCR |
|
Auto Pause / Auto Restart |
Yes |
|
Multi-user log in |
Password-based authentication protect personal PCR protocols |
|
Hold at 4℃ |
Yes,a below ambient temerature incubation allow PCR results storage overnight |
|
Program wizard |
Yes, template PCR protocol allow to create a new one with only a few clicks |
|
Running Report |
Yes, provide full review after protocol running |
|
PC Connection |
Yes |
|
Other Features |
|
|
Power |
Global switching power supply: 100V ~ 240V, 50--60Hz Max. 900W |
|
Dimension（L×W×H） |
375×270×277mm |
|
Net Weight |
13kgs |
